20BY46 PM Stepper Motor
 |
Introduction | |
| Application : | Optical Instrument | |
| IT Equipment | ||
| Download : | 20BY46.pdf | |
| Model |
Rated Voltage (V) |
Coil Resistance (Ω） |
Insulation Resistance （MΩS） |
Dielectric Strength |
Step Angle |
Drive Method |
Drive Circuit |
Insulation Grade |
|---|---|---|---|---|---|---|---|---|
| 20BY46 | 10.2 | 80 | 100 | AC500V 1S | 15° | 2-2phase | Bipolar | CLASS E |
