20BY45 PM Stepper Motor
 |
Introduction | |
| Application : | Thermal Printer | |
| Mini-printer | ||
| Precision Optical Instruments | ||
| Network Storage Module | ||
| Download : | 20BY45.pdf | |
| Model |
Rated Voltage (V) |
Coil Resistance (Ω） |
Insulation Resistance （MΩS） |
Dielectric Strength |
Step Angle |
Drive Method |
Drive Circuit |
Insulation Grade |
|---|---|---|---|---|---|---|---|---|
| 20BY45 | 5 | 40 | 100 | AC500V 1S | 18° | 2-2phase | Unipolar | CLASS E |
| 20BY45 | 24 | 20 | 100 | AC500V 1S | 18° | 2-2phase | Bipolar | CLASS E |
