15BY45 PM Stepper Motor
 |
Introduction | |
| Application : | Thermal Printer | |
| Monitoring Equipment | ||
| Download : | 15BY45.pdf | |
| Model |
Rated Voltage (V) |
Coil Resistance (Ω） |
Insulation Resistance （MΩS） |
Dielectric Strength |
Step Angle |
Drive Method |
Drive Circuit |
Insulation Grade |
|---|---|---|---|---|---|---|---|---|
| 15BY45 | 5 | 12 | 100 | AC500V 1S | 18° | 2-2phase | Bipolar | CLASS E |
| 15BY45 | 7.2 | 30 | 100 | AC500V 1S | 18° | 2-2phase | Bipolar | CLASS E |
