42BYG Hybrid Stepper Motor
 |
Introduction | |
| Application : | Medical Appliance | |
| Banking Terminal | ||
| Stage Lighting | ||
| Monitor System | ||
| Weighing Apparatus | ||
| Download : | 42BYG.pdf | |
| Model |
Voltage (V) |
Resistance (Ω） |
Inductance （mΩH） |
Pull-out Torque (mN.m) |
Holding Torque （mN.m) |
Max Start Frequency (PPS) |
Max Operation Frequency (PPS) |
Drive Method (Chopper） |
|---|---|---|---|---|---|---|---|---|
| 42BYGH005 | 12.3 | 44 | 21 | 120 | 160 | 1700 | 2700 | Unipolar |
| 42BYGH216 | 3.6 | 4.5 | 4 | 170 | 235 | 1600 | 3600 | Unipolar |
| 42BYGH924 | 9.6 | 18 | 15 | 130 | 260 | 1600 | 2500 | Unipolar |
| 42BYGH004 | 12 | 30 | 37 | 200 | 255 | 2200 | 3500 | Bipolar |
| 42BYGH206 | 2.87 | 3.3 | 5 | 190 | 235 | 2500 | 6000 | Bipolar |
| 42BYGH713 | 3.2 | 3.1 | 4.5 | 260 | 310 | 1800 | 400 | Bipolar |
