50SM40 Sunchronous Motor
 |
Introduction | |
| Application : | Valve Control | |
| Roaster | ||
| Electrical Andiron | ||
| Monitor Equipments | ||
| Download : | 50SM40.pdf | |
| Model |
Rated Voltage (V) |
Rated Frequency (Hz） |
Speed （RPM） |
Current (mA) |
Power （W） |
Output Torque （kgf.cm) |
Starting Voltage （V） |
Temperatuer Rising （K） |
| 50SM40 | 24 | 15 | 15 | ≤250 | ≤7 | ≥2 | ≤20 | ≤75 |
| 50SM40 | 24 | 20 | 20 | ≤250 | ≤7 | ≥1.5 | ≤20 | ≤75 |
| 50SM40 | 110/120 | 50/60 | 11.5/13.8 | ≤60 | ≤7 | ≥7 | ≤96 | ≤75 |
| 50SM40 | 110/120 | 50/60 | 11.7/14 | ≤60 | ≤7 | ≥6 | ≤96 | ≤75 |
| 50SM40 | 110/120 | 50/60 | 5/6 | ≤35 | ≤7 | ≥8 | ≤96 | ≤75 |
| 50SM40 | 220/240 | 50/60 | 5/6 | ≤35 | ≤7 | ≥8 | ≤176 | ≤75 |
| 50SM40 | 220/240 | 50/60 | 33.3/40 | ≤35 | ≤7 | ≥2.5 | ≤176 | ≤75 |
| 50SM40 | 220/240 | 50/60 | 11.5/13.8 | ≤35 | ≤7 | ≥8 | ≤176 | ≤75 |
| 50SM40 | 220/240 | 50/60 | 11.4/14 | ≤35 | ≤7 | ≥6 | ≤176 | ≤75 |
