50SM25-3 Sunchronous Motor
 |
Introduction | |
| Application : | Timer | |
| Download : | 50SM25-3.pdf | |
| Model |
Rated Voltage (V) |
Rated Frequency (Hz） |
Speed （RPM） |
Current (mA) |
Power （W） |
Stall Torque （N.m) |
Starting Voltage （V） |
Temperature Rising （K） |
| 50SM25-3 | 12 | 50/60 | 2 | ≤280 | ≤3 | ≥0.9 | ≤18 | ≤60 |
| 50SM25-3 | 24 | 50/60 | 2 | ≤150 | ≤3 | ≥0.9 | ≤18 | ≤60 |
| 50SM25-3 | 115 | 50/60 | 2 | ≤30 | ≤3 | ≥0.9 | ≤90 | ≤60 |
| 50SM25-3 | 220/240 | 50/60 | 2 | ≤20 | ≤3 | ≥0.9 | ≤180 | ≤60 |
| 50SM25-3 | 12 | 50/60 | 4/3 | ≤280 | ≤3 | ≥1.4 | ≤18 | ≤60 |
| 50SM25-3 | 24 | 50/60 | 4/3 | ≤150 | ≤3 | ≥1.4 | ≤18 | ≤60 |
| 50SM25-3 | 115 | 50/60 | 4/3 | ≤35 | ≤3 | ≥1.4 | ≤90 | ≤60 |
| 50SM25-3 | 220/240 | 50/60 | 4/3 | ≤20 | ≤3 | ≥1.4 | ≤180 | ≤60 |
| 50SM25-3 | 12 | 50/60 | 12 | ≤280 | ≤3 | ≥0.15 | ≤18 | ≤60 |
| 50SM25-3 | 24 | 50/60 | 12 | ≤150 | ≤3 | ≥0.15 | ≤18 | ≤60 |
| 50SM25-3 | 115 | 50/60 | 12 | ≤35 | ≤3 | ≥0.15 | ≤90 | ≤60 |
| 50SM25-3 | 220/240 | 50/60 | 12 | ≤20 | ≤3 | ≥0.15 | ≤180 | ≤60 |
