50SM25-1 Sunchronous Motor
 |
Introduction | |
| Application : | Timer | |
| Download : | 50SM25-1.pdf | |
| Model |
Rated Voltage (V) |
Rated Frequency (Hz） |
Speed （RPM） |
Current (mA) |
Power （W） |
Stall Torque （N.m) |
Starting Voltage （V） |
Temperature Rising （K） |
| 50SM25-1 | 120 | 60 | 1/30 | ≤30 | ≤3 | ≥1.41 | ≤90 | ≤60 |
| 50SM25-1 | 220/240 | 50/60 | 1 | ≤20 | ≤3 | ≥0.5 | ≤180 | ≤60 |
| 50SM25-1 | 120 | 60 | 1 | ≤30 | ≤3 | ≥0.5 | ≤90 | ≤60 |
| 50SM25-1 | 220/240 | 50/60 | 1/30 | ≤20 | ≤3 | ≥1.41 | ≤180 | ≤60 |
| 50SM25-1 | 24 | 50/60 | 1/30 | ≤130 | ≤3 | ≥1.41 | ≤18 | ≤60 |
| 50SM25-1 | 24 | 60 | 1 | ≤130 | ≤3 | ≥0.7 | ≤18 | ≤60 |
| 50SM25-1 | 220/240 | 50/60 | 0.9735 | ≤20 | ≤3 | ≥0.5 | ≤180 | ≤60 |
