57BYG Hybrid Stepper Motor
 |
Introduction | |
| Application : | Medical Appliance | |
| Banking Terminal | ||
| Stage Lighting | ||
| Monitor System | ||
| Weighing Apparatus | ||
| Download : | 57BYG.pdf | |
| Model |
Voltage (V) |
Resistance (Ω） |
Inductance （mΩH） |
Pull-out Torque (mN.m) |
Holding Torque （mN.m) |
Max Start Frequency (PPS) |
Max Operation Frequency (PPS) |
Drive Method (Chopper） |
|---|---|---|---|---|---|---|---|---|
| 57BYGH120 | 24 | 2.5 | 4 | 460 | 550 | 1700 | 3500 | Unipolar |
| 57BYGH101 | 8.4 | 12 | 25 | 360 | 490 | 1600 | 4500 | Bipolar |
| 57BYGH301 | 8.4 | 10.5 | 30 | 800 | 960 | 1500 | 2700 | Bipolar |
| 57BYGH402 | 6.7 | 7.5 | 25 | 850 | 980 | 1700 | 3500 | Bipolar |
